Environmental Testing Equipments

Description:

It is used for BOD Incubator samples of effluent and others. Double walled, heavily insulated. Automatic control & double door construction. Controlled by digital temperature controller inner stainless steel. Outer body ms duly powder coated/ stainless steel. The inner chamber is properly insulated with special grade puf to prevent thermal losses. Air circulating fan for uniform temperature.

Temperature range :5°C to 50°C.

Accuracy ±0.5°C.

Features:

• CFC Free Compressor.
• Full View Inner Glass Door.
• Lock And Key Arrangement.
• Caster Wheel Mounted Cabinet

Description:

A laboratory corrugating machine with digital temp. Controller for producing a sample to evaluate flat crush resistance of corrugating medium. 'A' fluting rolls are heated up to 176° C and maintained with a constant digital temperature controller. Standard model available with 'A' flute.

   Sample size 0.5 inch x 6 inch

Description:

Digital Humidity Meter indicates Ambient Humidity to an accuracy of about ± 2% ranging from zero to hundred percent. An imported versatile Phillips H1 sensor is used together with digital circuitry to measure, calibrate and store the data before displaying it on to the 3½ digit LEDS. Ambient temperature is also measured by LM-5 and displayed simultaneously on 3½ digit LEDS.

Features:

• Displays humidity to ± 2% and temperature to ± 10.C simultaneously.
• Large storage RAM (16K) for Data Acquisition and Computer downloading using timer control.
• Direct interface with any computer (RS. 232C).
• Software for analyzing and graphically displaying data.
• Built-in regulated power supply with optionally battery backup

Description:

A sample of a paper or board is conditioned and saidto be in equilibrium with the conditioning atmosphere when it has been exposed to the atmosphere long enough for the result of two weighings of a test piece,per formed at and interval of at least 1 hour. This method is suitable for conditioning of all type ofpaper and board before and during testing.

Technical Specification:

• A sample of a paper or board is conditioned and said to be in equilibrium with the conditioning
• Atmosphere when it has been exposed to the atmosphere long enough for the result of two weighings
• Of a test piece and interval of at least not to differ by more than 0.25 per cent.
• This method is suitable for conditioning of all type of paper and board before and during testing.

Option:

Digital Temperature indicator cum controller

Description:

Lab Hot Oven:

It is used for moisture determination of pulp,paper,and paperboard etc.

Double walled & heavily insulated.

Description:

Muffle Furnace:

 Muffle Furnace is used for incineration of solids. Temperature range up to 1000°C Working temperature 930° C Temperature controlled by energy regulator complete with Pyrometer and Thermocouple. Digital temp controller can be mounted on top side also.

Option:

Digital temperature indicator-cum controller.

Features:

• High performance
• Durability
• Reliable

Other Details:

• Castings are made of thick mild sheet reinforced with iron angles and painted with powder coating.
• Heating chamber consisting of regular horizontal shape totally enclosed muffle baked at 1200 ºC.
• Heating element meter made of kanthal wire.
• Light ceramic insulation provided into furnace body.
• Furnace are equipped with dependable indicator pyrometer having a scale calibrated in 25 increments at 1000º C.
• Silver fuse is provided to protect the heating elements pyrometer.
• Pyrometer is equipped with chrome alumel thermocouple.
• Furnace can be operated continuously up to 900º C.

Description:

Laboratory Oven:

• It is used for moisture determination of pulp,paper,and paperboard etc.
• Double walled & heavily insulated.
• Tempreture range : 50 C to 2500 C
• Accurancy ±0.5 C.
• Standard size :24”×24”×24”

Option:

Digital Temperature indicator cum controller.

Features:

• Easy to maintain
• Elevated performance
• Corrosion resistance

Description:

We are the leading supplier of Paper INK Proofing Kit made available to our clients at competitive prices.

It is used for visual assessment of color under different lighting conditions.

Features:

• Cabinet is made out of Powder Coated M.S. Sheet, Inside Color Munsell neutral grey.
• All tube lights are operated separately by electronic ballast.
• The electrical circuit is on a tray & is totally separate from the cabinet.
• Imported Hour Meter is for totalizing the time for Tube Lights.

Description:

Laboratory Oven:

• It is used for moisture determination of pulp,paper,and paperboard etc.
• Double walled & heavily insulated.
• Tempreture range : 50 C to 2500 C
• Accurancy ±0.5 C.
• Standard size :24”×24”×24”

Option:

Digital Temperature indicator cum controller.

Features:

• Easy to maintain
• Elevated performance
• Corrosion resistance

Description:

The water and soil analysis kits which are used to accurately analyze the given water & soil samples. We have different variants of this product. These instruments areThe water and soil analysis kits which are used to accurately analyze the given water & soil samples. We have different variants of this product. These instruments are successfully serving the specific soil and water analysis requirements of the clients, and offer a cost effective solution to their needs. successfully serving the specific soil and water analysis requirements of the clients, and offer a cost effective solution to their needs.

Features :

• Temperature Sensor: Semi Conductor Type
• TDS Range: 0-20 ppt
• TDS Accuracy: ±0.5 % FS ± 1 Digit
• DO Range: 0-20 ppm
• DO Resolution: 0.1 ppt
• DO Accuracy: 0.5 ppm ± 1 Digits
• DO Sensor: Gold / Silver Aerometric
• Turbidity Range: 0-1000 NTU
• Turbidity Resolution: 1 NTU
• Turbidity Accuracy: ±3 % ± 1 Digits
• Sample System: 30 mm Clear Glass
• Salinity Range: 0-50 ppt
