Analog Type Bursting Strength Tester

Description:

Analog Type Bursting Strength Tester is intended for measuring the bursting strength of strong paper & Boards by submitting it to increasing uniform hydraulic pressure. Single head with double pressure gauge on wall:

Gauge 1- 0-7 Kg/cm2

Gauge 2- 0-35 Kg/cm2

Salient Features:

• Heavy Duty Cast Iron body.
• Manual Clamping Pressure.
• Motor suspension in rubber cradle.
• Wheel with screw actuates the raising and lowering of the upper clamp.
• The Bursting Pressure, at the time of rupture is recorded on a sensitive pressure gauge.
• All pressure gauges are statically and dynamically calibrated.
• Two pressure gauges are fitted as standard.
• Units supplied with C spanner, 3 spare diaphragms, one alluminium foil and glycol topping- up fluid.
